CrystaLux DT 4-Pin Linkable Splitter Harness for Baja Designs LP Series Lights

SKU:
62-DT4BD-M
  • CrystaLux DT 4-Pin Linkable Splitter Harness for Baja Designs LP Series Lights
$22.95

Description

The CrystaLux Splitter pigtails allow you to easily daisy-chain multiple Baja Designs LP Series lights together. This allows for a cleaner installation when running multiple LP Series lights next to one another.

  • The 62-DT4BD-M Pigtail features a DTP 4-Pin Input Connector (daisy chains to the previous pigtail or connects to the power harness), a DT 4-Pin output (plugs into the light) & a DTP 4-Pin Output Connector (daisy chains to the next pigtail).
  • The 62-DT4BD-T Terminating Pigtail features a DTP 4-Pin Input Connector (daisy chains to the previous pigtail) & two (2) DT 4-Pin outputs (plugs into 2 lights).

Each Pigtail utilizes four (4) 10 gauge wires on the main harness/DTP connectors (which daisy chain to each other) with four (4) 14 gauge wires going to the DT 4-Pin Output Connectors (which plugs into the light).

Please note that there is a maximum number of Baja Designs LP Series lights that can be daisy chained together to one power source. Those are as follow:

  • Max # of Baja Designs LP4 Lights: 6
  • Max # of Baja Designs LP6 Lights: 6
  • Max # of Baja Designs LP9 Sport Lights: 8
  • Max # of Baja Designs LP9 Pro Lights: 5
  • Max # of Baja Designs LP9 Racer Lights: 5

Please use the following chart to determine the total number of pigtails & terminating pigtails that will be required for your installation:

You'll also need a main power harness with a 4-Pin DTP connector as well to provide power to the system. We currently do not offer a CrystaLux harness for this however we do sell a harness made by Diode Dynamics that we customize to work with the LP Series Lights (this harness is customized by us prior to shipping to follow the same pin-out configuration as the Baja Designs LP Series lights). That harness is available here: https://www.4x4truckleds.com/diode-dynamics-ultra-heavy-duty-single-output-4-pin-wiring-harness-for-crystalux-dt-4-pin-linkable-splitters/
